SOCKET FUSION

Vali PPR 63 series of plastic pipe socket fusion tools are hand-held electronic tools for heating and joining plastic & fittings. They can be effectively for welding of PPR, PVDF, PP, HDPE and PB

MODEL VPWS 630 VPWS 800 VPWS 1000
Pipe welding ranges (mm)
315, 355, 400, 450, 500, 560, 630
450, 500, 560, 630, 710, 800
630, 710, 800, 900, 1000
Working voltage
380V, 3P, 50/60 Hz
380V, 3P, 50/60 Hz
380V, 3P, 50/60 Hz
Heating Plate Max. Temp
270 °C
270 °C
270 °C
Deviation in heating plate surface temperature
<±7 °C
<±7 °C
<±7 °C
Pressure adjustment ranges
0-8 Mpa
0-16 Mpa
0-16 Mpa
Heating plate power
9.35kw
12.5kw
17.5kw
Planning tool power
1.5kw
2.2kw
3kw
Hydraulic unit power
1.5kw
3kw
3kw
Crane power
1.1kw
1.1kw
1.1kw
Total power
12.35kw
18.7kw
24.5kw
Weight
780 kg
1360 kg
2600 kg
Optional
Stub Flange Adapter, Compact trolley, Data logger
